AUTOMATIC SWITCHING
POWER SUPPLY
Auto-switch between
110V-260V. No power
configuration needed,
this power supply is
specially designed to
noisy power supply
lines. It constantly
regulates the incoming
supply and ensures
constant vlotage and
current supply to
controller hardware
so that any sudden
power surge will not
cause any damage.

RELIABLE RELAY &
MEASUREMENT CARDS
OKTEK used specially
tested contact relays
(burn-in-tests) for
relay card and reed
relays for measurement
cards to ensure more
reliable and accurate
result.

AUTOMATIC DISCHARGE
FUNCTION
The function of auto
voltage detect and
auto discharge to
improve the accuracy
of testing and protect
the relay board been
damaged.

SELF DIAGNOSTIC PROGRAM
Relay board check and
DC/AC measurement card
check available to help
isolate and identify
system failures.

TESTING RESISTANCE LOWER
THAN 1Ω
When test the resistance
lower than 1Ω, auto deduct
 the contact resistance
(R0). It can test low
resistance with accuracy
and stability.
Also able to use 4 probes
(Kelvin Test)(2 probes
each side of component)
to test the resistance
above 0.1Ω stably.

VARIOUS IC TEST MODES
1.open/short Test
2.Diode Test
3.Open Scan Test :Use
the current which
measured through diode
to test IC pin's short
and open, and solve the
problem of parallel
diode's loss effectively.

4.TestJet : Option
